Cummins 550 kVA Diesel Generator

Cummins 550 kVA Diesel Generator Specification

Standard
ISO 8528 / IS 4722

Pressure
Compression Ratio 14.5:1

Engine Model
KTAA19-G9

Bore *Stroke
159 mm x 159 mm

Fuel Tank Capacity
990 Litres

Insulation
Class H

Fuel Consumption
105 Litres/hour (at 100% load)

Alternator
Stamford / Cummins

Protection Class
Over voltage protection

Dimension (L*W*H)
4300 x 1620 x 2160 mm

Engine Type
Turbocharged, Aftercooled

Poles Number
4

Product Type
Diesel Generator

Output Type
AC

Rated Power
550 kVA

Rated Voltage
220-440 Volt (V)

Starting Type
Electric Start

Rated Frequency
50-60 Hertz (HZ)

Power Range
500-550 kVA

Color
Green

Cooling System
Air Cooled

Noise Level
75 dB(A) @ 1m

Phase
Three Phase

Speed
1500 RPM

Weight
5800 kg

Frequency Regulation
1%

Control Panel
Microprocessor based

No. of Cylinders
6 In-line

Battery Capacity
2 x 180 Ah

Lubrication Oil Capacity
50 Litres

Aspiration
Turbocharged

Voltage Regulation
1%

Cooling Medium
Water/Glycol

Cummins 550 kVA Diesel Generator Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
2-10 Days

Main Domestic Market
Karnataka

About Cummins 550 kVA Diesel Generator

The Cummins 550 kVA CPCB IV Plus Compliant Genset is a reliable power solution for various applications. With a rated voltage of 415V, this genset ensures steady power supply. It is equipped with overvoltage protection for enhanced safety. The cooling system can be oil, water, or air cooled, providing flexibility based on requirements. The electric start feature simplifies the operation of the genset, making it user-friendly. Operating at a rated frequency of 50Hz, this genset is designed to deliver consistent performance even in demanding conditions.

FAQs of Cummins 550 kVA CPCB IV Plus Compliant Genset:

Q: What is the rated voltage of the Cummins 550 kVA CPCB IV Plus Compliant Genset?

A: The rated voltage of 415V.

Q: What type of protection class does the genset have?

A: The genset is equipped with overvoltage protection.

Q: How does the cooling system of the genset work?

A: The cooling system can be oil, water, or air cooled based on requirements.

Q: What is the starting type of the genset?

A: The genset has an electric start feature for easy operation.

Q: At what frequency does the genset operate?

A: The genset operates at a rated frequency of 50Hz.

We are dealing for Banglore location only.

Advanced Control and Reliability

Equipped with a microprocessor-based control panel, this generator provides intelligent management and high-precision monitoring. Its reliable 6-cylinder, turbocharged engine ensures consistent output. The water/glycol cooling system keeps operating temperatures optimal even under heavy loads, prolonging engine life.

Efficient Operation and Robust Design

The Cummins 550 kVA generator combines efficiency with practicality. With fuel consumption of 105 litres per hour at full load and a large 990-litre fuel tank, it delivers extended operation with less frequent refueling. The soundproof design maintains noise levels at 75 dB(A) @ 1m, ensuring quieter operations.

Comprehensive Safety and Compliance

Designed for safety, the generator includes over voltage protection and is built to meet ISO 8528 and IS 4722 standards. The high-class insulation and protection class enhance safe operation, suitable for critical facilities and sensitive equipment.

FAQ's of Cummins 550 kVA Diesel Generator:

Q: How does the frequency and voltage regulation benefit my operations?

A: With 1% frequency and voltage regulation, the Cummins 550 kVA generator ensures highly stable power output, protecting sensitive equipment from harmful fluctuations and thereby maintaining consistent operational efficiency.

Q: What type of cooling system does this generator use, and where is it most effective?

A: This generator employs a water/glycol cooling system for the engine and air cooling for the alternator, making it effective in a variety of Indian climates and ideal for continuous or standby power generation in industrial, commercial, or institutional settings.

Q: When should I schedule routine maintenance for optimal performance?

A: Routine maintenance should be performed every 250-500 operating hours or as recommended in the owner's manual, including checks on lubrication oil, coolant, and battery condition to ensure continued reliability.

Q: Where can this generator be installed, and what are the site requirements?

A: It can be installed in indoor or outdoor locations with adequate ventilation, level ground, and protection from extreme weather. Proper clearances, as per the installation manual, enable efficient cooling and easy access for servicing.

Q: What is the process for starting and operating the Cummins 550 kVA Diesel Generator?

A: The generator features an electric start system. After a thorough pre-start inspection (fuel, oil, coolant levels), simply engage the electric starter via the microprocessor panel. The control system then manages operation and monitors performance.

Q: How can I maximize the usage and lifespan of this generator?

A: To maximize performance and longevity, operate the generator within rated capacities, perform regular maintenance, use clean diesel fuel, and monitor the control panel alerts for any anomalies. Adhering to manufacturer's guidelines also extends service life.

Q: What are the key benefits of choosing this Cummins generator for my facility?

A: You gain robust, continuous power with reliable frequency and voltage regulation, low noise, high safety standards, and a design optimized for Indian conditions. Its sizeable fuel tank and efficient consumption allow extended, uninterrupted operation.
